MATERIAŁ:
Stal ocynk galw. biały
Stal nierdzewna A2
Wymiary
| Rozmiar M | d2 | p | s (L > 3 x d1) | s (L < 3 x d1) | SW | D | K |
|---|---|---|---|---|---|---|---|
| 3.0 | 1,66 | 1,34 | 3,0 | 1,5 | 5,0 | 6,5 | 2,3 |
| 3.5 | 1,91 | 1,57 | 3,5 | 1,8 | 5,5 | 7,0 | 2,8 |
| 4.0 | 2,17 | 1,79 | 4,0 | 2,0 | 5,5 | 8,0 | 2,8 |
| 5.0 | 2,68 | 2,24 | 5,0 | 2,5 | 7,0 | 10,0 | 3,5 |
| 6.0 | 3,19 | 2,69 | 6,0 | 3,0 | 8,0 | 12,0 | 3,5 |
| 7.0 | 3,70 | 3,14 | 7,0 | 3,5 | 8,0 | 14,0 | 5,0 |
